Wood Grapple Main Features:
1). Unlimited clockwise and anti-clockwise 360° rotatable
2). Equipped with Hydraulic Rotor extra effective and stable;
3). Original German oil seals, making cylinder extra long lasting and safe;
4). Equipped with heat-dealt with shaft.
RUNMING Wood Grapple is a shape of Boom wooden craner attachments which
Is particularly used for wooden, log, wooden, stone, rock and particular huge scraps handing, moving, loading and organizing.
RUNMING Wood Grab Log Grapple
As one of the critical Log Grapple manufacturer in China, RUNMING has a whole shape of log grapples for increase wooden crane from 0.5-5ton.They are suitable for all styles of producers and models of wooden crane.
model | A | B | C | D | E | F | G | H | I | K | weight | Work pressure | Maximum grab weight |
TG10 | 605 | 708 | 918 | 620 | 638 | 0.1 | 568 | 410 | φ65 | 285 | 48kg | 18Mpa | 500kg |
TG12 | 610 | 800 | 972 | 612 | 651 | 0.12 | 580 | 389 | φ60 | 285 | 53kg | 18Mpa | 500kg |
TG16 | 638 | 1080 | 1228 | 682 | 728 | 0.16 | 713 | 455 | φ60 | 305 | 72kg | 18Mpa | 800kg |
TG16Z | 638 | 1080 | 1228 | 682 | 728 | 0.16 | 713 | 455 | φ60 | 305 | 80kg | 21Mpa | 1000kg |
TG18 | 718 | 1080 | 1282 | 747 | 775 | 0.18 | 717 | 456 | φ65 | 306 | 75kg | 21Mpa | 1000kg |
TG18Z | 718 | 1080 | 1282 | 747 | 775 | 0.18 | 717 | 456 | φ65 | 305 | 85KG | 21Mpa | 1200kg |
TG20 | 689 | 1260 | 1390 | 765 | 790 | 0.2 | 766 | 468 | φ65 | 368 | 113kg | 21Mpa | 1500kg |
TG20Z | 689 | 1260 | 1390 | 765 | 790 | 0.2 | 766 | 468 | φ65 | 368 | 120kg | 21Mpa | 2000kg |
TG26 | 740 | 1470 | 1620 | 872 | 885 | 0.26 | 819 | 507 | φ70 | 398 | 143kg | 21Mpa | 2500kg |
TG36 | 970 | 1620 | 1845 | 1028 | 1130 | 0.36 | 974 | 620 | φ105 | 465 | 218kg | 21Mpa | 3000kg |
TG45 | 1040 | 1920 | 2100 | 1152 | 1192 | 0.45 | 1074 | 718 | φ110 | 532 | 272kg | 21Mpa | 3500kg |
